Description
Parameters
| Model | W（mm） | W1（mm） | H（mm） | H1（mm） | D（mm） | S1（mm） |
| VFD110VL43C-J | 235 | 204 | 350 | 337 | 146 | 6.5 |
| VFD150VL43C-J | 235 | 204 | 350 | 337 | 146 | 6.5 |
| VFD185VL43C-J | 235 | 204 | 350 | 337 | 146 | 6.5 |
| VFD220VL43C-J | 235 | 204 | 350 | 337 | 146 | 6.5 |
| VFD300VL43C-J | 255 | 226 | 403.8 | 384 | 168 | 8.5 |
| VFD370VL43C-J | 255 | 226 | 403.8 | 384 | 168 | 8.5 |
| VFD450VL43C-J | 330 | 285 | 565 | 540 | 273.4 | 11.0 |
| VFD550VL43C-J | 330 | 285 | 565 | 540 | 273.4 | 11.0 |
| VFD750VL43C-J | 330 | 285 | 565 | 540 | 273.4 | 11.0 |
| VFD300VL43A-J | 370 | 335 | 589 | 560 | 260 | 13.0 |
| VFD370VL43A-J | 370 | 335 | 589 | 560 | 260 | 13.0 |
| VFD450VL43A-J | 370 | 335 | 589 | 560 | 260 | 13.0 |
| VFD550VL43A-J | 370 | 335 | 589 | 560 | 260 | 13.0 |
| VFD750VL43A-J | 370 | 335 | 589 | 560 | 260 | 13.0 |
Field Oriented Control
– Suitable for both synchronous servo motors and asynchronous servo motorsBuilt-in brake unit
– RS-485 communication interface (RJ-45) and standard Modbus communication protocol
– Precise current detection for system protection with safety ensured
– Suitable for both synchronous servo motors and asynchronous servo motorsBuilt-in brake unit
– RS-485 communication interface (RJ-45) and standard Modbus communication protocol
– Precise current detection for system protection with safety ensured
– New software for PC connection allows real time monitoring of AC motor drive status
When pressure and flow instructions are given to the injection molding machine, the Delta VFD-VJ series begins PID calculation simultaneously to attain the actual pressure and speed feedback data, and drive the servo motor and the hydraulic pump. The Delta VFD-VJ series offers you a system with fast response and high duplication accuracy.
Injection Molding Machine
Die Casting Machine
Hydraulic Machine
Hydraulic Press
